Product Summary

The TL084CN is an operational amplifier. The BIFET technology provides wide bandwidths and fast slew rates with low input bias currents, input offset currents, and supply currents. These devices are available in single, dual and quad operational amplifiers which are pin–compatible with the industry standard MC1741, MC1458, and the MC3403/LM324 bipolar products.

Parametrics

TL084CN absolute maximum ratings: (1)Supply voltage: 18V; (2)differential input voltage: 30V; (3)input voltage range: 15V; (4)output short circuit duration: continuous; (5)power dissipation: 680mW; (6)operating ambient temperature range: 0 to 70℃; (7)storage temperature range: -65 to 150℃.

Features

TL084CN features: (1)Low Input Bias Current: 30 pA; (2)Low Input Offset Current: 5.0 pA; (3)Wide Gain Bandwidth: 4.0 MHz; (4)High Slew Rate: 13 V/ms; (5)Low Supply Current: 1.4 mA per Amplifier; (6)High Input Impedance: 1012 W.

Diagrams

TL084CN pin connections

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TL084CNE4
TL084CNE4
Texas Instruments
Operational Amplifiers - Op Amps Quad JFET-Input
Data Sheet
0-1: $0.34
1-25: $0.28
25-100: $0.23
100-250: $0.20
TL084CNSR
TL084CNSR
Texas Instruments
Operational Amplifiers - Op Amps Quad JFET Neg Input
Data Sheet
0-1: $0.35
1-25: $0.26
25-100: $0.22
100-250: $0.19
TL084CNSRG4
TL084CNSRG4
Texas Instruments
Operational Amplifiers - Op Amps Quad JFET-Input
Data Sheet
0-1: $0.40
1-25: $0.28
25-100: $0.24
100-250: $0.19
TL084CN
TL084CN
STMicroelectronics
Operational Amplifiers - Op Amps Quad Gen Purp JFET
Data Sheet
0-1: $0.35
1-10: $0.26
10-100: $0.22
100-250: $0.19
