Product Summary
The KPC357NT is a mini-flat package general purpose photo coupler. Its applications include Hybrid substrates that reguire high density mounting, Programmable controllers.
Parametrics
KPC357NT absolute maximum ratings: (1)forward current: 50mA; (2)peak forward current: 1A; (3)reverse voltage: 6V; (4)power dissipation: 70mW; (5)collector-emitter voltage: 60V; (6)emitter-collector voltage: 5V; (7)collector current: 50mA; (8)collector power dissipation: 150mW.
Features
KPC357NT features: (1)Opaque type, mini-flat package; (2)Subminiature type (The volume is smaller than that of our conventional DIP type by as far as 30%); (3)Current transfer ratio (CTR:MIN.50% at IF=5mA, Vce=5V); (4)Isolation voltage between input and output (Viso:3750Vrms).
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||
---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() KPC357NT |
![]() Other |
![]() |
![]() Data Sheet |
![]() Negotiable |
|
||||
