Product Summary

The TIP32C is a silicon Epitaxial-base power transistor. Its applications include linear and switching industrial equipment.

Parametrics

TIP32C absolute maximum ratings: (1)collector-emitter voltage: 100V; (2)collector-base voltage: 100V; (3)emitter-base voltage: 5V; (4)collector-current-continuous: 3A; (5)collector current- peak: 5A; (6)base current: 1A.

Features

TIP32C features: (1)collector-emitter sustaining voltage; (2)collector-emitter saturation voltage; (3)current gain-bandwidth product.

Diagrams

TIP32C diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TIP32C-BP
TIP32C-BP
Micro Commercial Components (MCC)
Transistors Bipolar (BJT) PNP -100V -3A 40W
Data Sheet
0-1: $0.41
1-10: $0.32
10-25: $0.27
25-100: $0.25
TIP32CE3
TIP32CE3
Other

Data Sheet
Negotiable
TIP32CF
TIP32CF
Other

Data Sheet
Negotiable
TIP32C-S
TIP32C-S
Bourns
Transistors Bipolar (BJT) 100V 3A PNP
Data Sheet
0-15000: $0.29
15000-20200: $0.29
TIP32CTSTU
TIP32CTSTU
Fairchild Semiconductor
Transistors Bipolar (BJT) PNP Epitaxial Sil Short Leads
Data Sheet
Negotiable
TIP32CTU
TIP32CTU
Fairchild Semiconductor
Transistors Bipolar (BJT) PNP Epitaxial Silicon Transistor
Data Sheet
0-1: $0.34
1-25: $0.25
25-100: $0.21
100-250: $0.18
TIP32CG
TIP32CG
ON Semiconductor
Transistors Bipolar (BJT) 3A 100V 40W PNP
Data Sheet
0-1: $0.31
1-25: $0.27
25-100: $0.19
100-500: $0.16
TIP32C
TIP32C
Fairchild Semiconductor
Transistors Bipolar (BJT) PNP Epitaxial Sil
Data Sheet
0-1: $0.28
1-25: $0.24
25-100: $0.20
100-250: $0.18
