Product Summary
The XC95288XL-10TQG144C is a High Performance CPLD.
Parametrics
Absolute maximum ratings: (1)Supply voltage relative to GND: –0.5 to 4.0 V; (2)Input voltage relative to GND: –0.5 to 5.5 V; (3)Voltage applied to 3-state output: –0.5 to 5.5 V; (4)Storage temperature (ambient): –65 to +150 ℃; (5)Maximum soldering temperature (10s @ 1/16 in. = 1.5 mm): +260 ℃; (6)Junction temperature: +150 ℃.
Features
Features: (1)6 ns pin-to-pin logic delays; (2)System frequency up to 208 MHz; (3)288 macrocells with 6,400 usable gates; (4)Fast concurrent programming; (5)Slew rate control on individual outputs; (6)Enhanced data security features; (7)Excellent quality and reliability.
Diagrams
<IMG border=0 src="http://www.seekic.com/uploadfile/ic-mfg/201271715156590.jpg">
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
XC95288XL-10TQG144C |
IC CPLD 6.4K 288MCELL 144-TQFP |
Data Sheet |
|
|
||||||||||||||||||
