IRF9540N

power MOSFET, 100V, 23A, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.21~0.21 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.21~0.21

PartNumber:: IRF9540N

Brand:: International Rectifier - IR | Pack: TO | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Gardenias's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-06

From Other Seller

Part Number:IRF9540N
US $0.21 - 0.21
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRF9540N is a power MOSFET. It utilizes advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that HEXFET Power MOSFETs are well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The TO-220 package is universally preferred for all commercial-industrial applications at power dissipation levels to approximately 50 watts. The low thermal resistance and low package cost of the TO-220 contribute to its wide acceptance throughout the industry.

Parametrics

IRF9540N absolute maximum ratings: (1)continuous drain current: -23A; (2)continuous drain current @TC=100℃: -16A; (3)pulsed drain current: -76A; (4)power dissipation: 140W; (5)linera derating factor: 0.91W/℃; (6)single pulse avalanche energy: 430mJ; (7)avalanche current: -11A; (8)repetitive avalanche energy: 14mJ.

Features

IRF9540N features: (1)Advanced Process Technology; (2)Dynamic dv/dt Rating; (3)175°C Operating Temperature; (4)Fast Switching; (5)P-Channel; (6)Fully Avalanche Rated.
