Product Summary
The MAX232N is a dual driver/receiver that includes a capacitive voltage generator to supply TIA/EIA-232-F voltage levels from a single 5-V supply. Each receiver converts TIA/EIA-232-F inputs to 5-V TTL/CMOS levels. These receivers have a typical threshold of 1.3 V, a typical hysteresis of 0.5 V, and can accept ±30-V inputs. Each driver converts TTL/CMOS input levels into TIA/EIA-232-F levels. The driver, receiver, and voltage-generator functions are available as cells in the Texas Instruments LinASIC library.
Parametrics
MAX232N absolute maximum ratings: (1)Input supply voltage range, VCC: -0.3 V to 6 V; (2)Positive output supply voltage range, VS+: VCC . 0.3 V to 15 V; (3)Negative output supply voltage range, VS: -0.3 V to -15 V; (4)Input voltage range, VI: Driver: -0.3 V to VCC + 0.3 V; Receiver: ±30 V; (5)Output voltage range, VO: T1OUT, T2OUT: VS_-0.3 V to VS+ + 0.3 V; R1OUT, R2OUT: -0.3 V to VCC + 0.3 V; (6)Short-circuit duration: T1OUT, T2OUT: Unlimited; (7)Package thermal impedance, θJA (see Notes 2 and 3): D package: 73℃/W; DW package: 57℃/W; N package: 67℃/W; NS package: 64℃/W; (8)Operating virtual junction temperature, TJ: 150℃; (9)Storage temperature range, Tstg: -65℃ to 150℃.
Features
MAX232N features: (1)Meets or Exceeds TIA/EIA-232-F and ITU Recommendation V.28; (2)Operates From a Single 5-V Power Supply With 1.0-uF Charge-Pump Capacitors; (3)Operates Up To 120 kbit/s; (4)Two Drivers and Two Receivers; (5)±30-V Input Levels; (6)Low Supply Current: 8 mA Typical; (7)ESD Protection Exceeds JESD 22: 2000-V Human-Body Model (A114-A); (8)Upgrade With Improved ESD (15-kV HBM)and 0.1-uF Charge-Pump Capacitors is Available With the MAX202; (9)Applications: TIA/EIA-232-F, Battery-Powered Systems, Terminals, Modems, and Computers.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MAX232N |
Texas Instruments |
Buffers & Line Drivers Dual RS232 Driver |
Data Sheet |
|
|
||||||||||||
|
MAX232NE4 |
Texas Instruments |
RS-232 Interface IC Dual EIA-232 Driver/ Receiver |
Data Sheet |
|
|
||||||||||||
|
MAX232NSR |
Texas Instruments |
Buffers & Line Drivers Dual EIA-232 Driver/ Receiver |
Data Sheet |
|
|
||||||||||||
|
MAX232NSRE4 |
Texas Instruments |
RS-232 Interface IC Dual EIA-232 Driver/ Receiver |
Data Sheet |
|
|
||||||||||||
|
MAX232NSRG4 |
Texas Instruments |
RS-232 Interface IC Dual EIA-232 Driver/ Receiver |
Data Sheet |
|
|
||||||||||||
