Product Summary

The MAX1470EUI-T is a fully integrated low-power CMOS superheterodyne receiver for use with amplitude-shift-keyed (ASK) data in the 315MHz band.

Parametrics

Absolute maximum ratings: (1)AVDD to AGND:-0.3V to +4.0V; (2)DVDD to DGND:-0.3V to +4.0V; (3)All Other Pins Referenced to AGND:-0.3V to (VDD + 0.3V); (4)Continuous Power Dissipation (TA = +70℃):1039mW; (5)Storage Temperature Range:-60℃ to +150℃; (6)Lead Temperature (soldering, 10s):+300℃.

Features

Features: (1)Operates from a Single +3.0V to +3.6V Supply; (2)Built-In 53dB RF Image Rejection; (3)-115dBm Receive Sensitivity; (4)250μs Startup Time; (5)Low 5.5mA Operating Supply Current; (6)1.25μA Low-Current Power-Down Mode for Efficient Power Cycling; (7)250MHz to 500MHz Operating Band (Image Rejection Optimized at 315MHz); (8)Integrated PLL with On-Board Voltage-Controlled Oscillator (VCO) and Loop Filter; (9)Selectable IF Bandwidth Through External Filter; (10)Complete Receive System from RF to Digital Data Out.
