Product Summary
The LVR012K is a polyswitch resettable device. It helps protect electric motors and transformers used in commercial and home appliances from damage caused by mechanical overloads, overheating, stall, lost neutral and other potentially harmful conditions. The applications of the LVR012K include electromagnetic loads, medical equipment, security and fire alarm systems, test and measurement equipment, transformers, POS equipment, USB hubs, ports and peripherals.
Parametrics
LVR012K absolute maximum ratings: (1)IH: 0.12A; (2)IT: 0.3A; (3)Operating VMAX: 240V; (4)Interrupt VMAX: 265V; (5)IMAX interrupt: 1.2A; (6)RMIN: 3000Ω; (7)PDTYP: 1W.
Features
LVR012K features: (1)RoHS compliant; (2)Broadest range of radial-leaded resettable devices available in the industry; (2)Current ratings from 50mA to 2A; (3)Line voltage rating of 120VAC and 240VAC; (4)Agency recognition : UL, CSA, TuV; (5)Fast time-to-trip; (5)Low resistance.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LVR012K |
TE Connectivity / Raychem |
PTC Resettable Fuses .12A 240VAC 20/1.2A Imax |
Data Sheet |
|
|
|||||||||||||
LVR012K-2 |
TE Connectivity / Raychem |
PTC Resettable Fuses 240V 2Pin T/R LN VOLTAGE PRODUCTS |
Data Sheet |
|
|
