Product Summary
Logic Supply 5V at 10A
5V Logic to ±15V Op Amp Supply
Battery Upconverter
Power Inverter (+ to –) or (– to +)
Fully Floating Multiple Outputs
Features
Wide Input Voltage Range: 3V to 60V
n Low Quiescent Current: 6mA
n Internal 5A Switch (2.5A for LT1171,
1.25A for LT1172)
n Shutdown Mode Draws Only 50mA Supply Current
n Very Few External Parts Required
n Self-Protected Against Overloads
n Operates in Nearly All Switching Topologies
n Flyback-Regulated Mode Has Fully Floating Outputs
n Comes in Standard 5-Pin Packages
n LT1172 Available in 8-Pin MiniDIP and Surface Mount
Packages
n Can Be Externally Synchronized
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1171CT |
|
IC REG MULTI CONFIG ADJ TO220-5 |
Data Sheet |
|
|
||||||||||
|
LT1171CT#06PBF |
|
IC REG MULTI CONFIG ADJ TO220-5 |
Data Sheet |
|
|
||||||||||
|
LT1171CT#PBF |
|
IC REG MULTI CONFIG ADJ TO220-5 |
Data Sheet |
|
|
||||||||||
