Product Summary
The LMV931MGX is a RRIO operational amplifier. Its applications include Consumer communication, Consumer computing, PDAs, Audio pre-amp, Portable/battery-powered electronic equipment, Supply current monit, Battery monitoring.
Parametrics
LMV931MGX absolute maximum ratings: (1)ESD tolerance: 200V; (2)differential input voltage: ±supply voltage; (3)supply voltage: 5.5V; (4)storage temperature range: -65 to 150℃; (5)junction temperature: 150℃; (6)ESD tolerance, human body model: 2000V.
Features
LMV931MGX features: (1)(Typical 1.8V Supply Values; Unless Otherwise Noted) Guaranteed 1.8V, 2.7V and 5V specifications output swing; (2)VCM 200mV beyond rails; (3)current (per channel) 100μA; (4)Gain bandwidth product 1.4MHz; (5)Maximum VOS 4.0mV; (6)Ultra tiny packages; (7)Temperature range: -40°C to 125°C.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() LMV931MGX |
![]() National Semiconductor (TI) |
![]() Operational Amplifiers - Op Amps |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() LMV931MGX/NOPB |
![]() National Semiconductor (TI) |
![]() Operational Amplifiers - Op Amps |
![]() Data Sheet |
![]()
|
|
