Product Summary

The LM358DR2G is a single supply dual operational amplifier. Utilizing the circuit designs perfected for Quad Operational Amplifiers, the LM358DR2G feature low power drain, a common mode input voltage range extending to ground/VEE, and single supply or split supply operation. The LM358DR2G series is equivalent to one?half of an LM324. These amplifiers have several distinct advantages over standard operational amplifier types in single supply applications. They can operate at supply voltages as low as 3.0 V or as high as 32 V, with quiescent currents about one?fifth of those associated with the MC1741 (on a per amplifier basis). The common mode input range includes the negative supply, thereby eliminating the necessity for external biasing components in many applications. The output voltage range also includes the negative power supply voltage.

Parametrics

LM358DR2G absolute maximum ratings: (1)power supply voltage: 32V; (2)input differential voltage range: ±32V; (3)input common mode voltage range: -0.3 to 32V; (4)output short circuit duration: continuous; (5)junction temperature: 150℃; (6)storage temperature range: -65 to 150℃; (7)thermal resistance: 238℃/W.

Features

LM358DR2G features: (1)Short Circuit Protected Outputs; (2)True Differential Input Stage; (3)Single Supply Operation: 3.0 V to 32 V; (4)Low Input Bias Currents; (5)Internally Compensated; (6)Common Mode Range Extends to Negative Supply; (7)Single and Split Supply Operation; (8)ESD Clamps on the Inputs Increase Ruggedness of the Device without Affecting Operation; (9)Pb-Free Packages are Available; (10)NCV Prefix for Automotive and Other Applications Requiring Site and Control Changes.

Diagrams

LM358DR2G pin connections

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LM358DR2G
LM358DR2G

ON Semiconductor

Operational Amplifiers - Op Amps 3-32V Dual Lo PWR Commercial Temp

Data Sheet

0-1: $0.26
1-25: $0.17
25-100: $0.14
100-500: $0.09
