Product Summary

The 74HC4066D is a quad bilateral switch. The 74HC4066D havs four independent analog switches. Each switch has two input/output terminals (nY, nZ) and an active HIGH enable input (nE). When nE is LOW the belonging analog switch is turned off. The "4066" is pin compatible with the "4016" but exhibits a much lower "ON" resistance. In addition, the "ON"resistance is relatively constant over the full input signal range.

Parametrics

74HC4066D absolute maximum ratings: (1)DC supply voltage: 1V; (2)DC digital input diode current: 20mA; (3)DC switch diode current: 20mA; (4)DC switch current: 25mA; (5)DC VCC or GND current: 50mA; (6)storage temperature range: -65 to 150℃; (7)power dissipation per package: 750mW; (8)power dissipation per switch: 100mW.

Features

74HC4066D features: (1)very low "on" resistance; (2)output capability: non-standard; (3)ICC category: SSI.

Diagrams

74HC4066D diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
74HC4066D
74HC4066D
NXP Semiconductors
Analog Switch ICs QUAD BILATERL SWITCH
Data Sheet
Negotiable
74HC4066D,652
74HC4066D,652
NXP Semiconductors
Analog Switch ICs QUAD BILATERL SWITCH
Data Sheet
0-1: $0.07
1-25: $0.06
25-100: $0.06
100-250: $0.05
74HC4066DB,118
74HC4066DB,118
NXP Semiconductors
Analog Switch ICs QUAD BILATERAL
Data Sheet
0-1: $0.27
1-25: $0.23
25-100: $0.19
100-250: $0.15
74HC4066DB,112
74HC4066DB,112
NXP Semiconductors
Analog Switch ICs QUAD BILATERAL
Data Sheet
0-1: $0.14
1-25: $0.13
25-100: $0.11
100-250: $0.09
74HC4066D,653
74HC4066D,653
NXP Semiconductors
Analog Switch ICs QUAD BILATERAL SWTCH
Data Sheet
0-1: $0.07
1-25: $0.06
25-100: $0.06
100-250: $0.05
74HC4066DB
74HC4066DB
NXP Semiconductors
Analog Switch ICs QUAD BILATERAL SWITCH
Data Sheet
Negotiable
74HC4066DB-T
74HC4066DB-T
NXP Semiconductors
Analog Switch ICs QUAD BILATERAL SWITCH
Data Sheet
Negotiable
