Product Summary

The UA741CN is a high performance monolithic operational amplifier constructed on a single silicon chip. It is intended for a wide range of analog applications. The high gain and wide range of operating voltages provide superior performances in integrator, summing amplifier and general feedback applications. The internal compensation network (6 dB/octave) ensures stability in closedloop circuits. The applications of the UA741CN include Summing amplifiers, Voltage followers, Integrators, Active filters, Function generators.

Parametrics

UA741CN absolute maximum ratings: (1)supply voltage: 22V; (2)Input voltage: 15V; (3)differential input voltage: 30V; (4)power dissipation: 500mW; (5)operating free-air temperature range: 0 to 70℃; (6)storage temperature range: -65 to 150℃.

Features

UA741CN features: (1)Large input voltage range; (2)No latch-up; (3)High gain; (4)Short-circuit protection; (5)No frequency compensation required; (6)Same pin configuration as the UA709.

Diagrams

UA741CN diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
UA741CN
UA741CN
STMicroelectronics
Operational Amplifiers - Op Amps Single General Purp
Data Sheet
0-1: $0.18
1-10: $0.17
10-100: $0.14
100-250: $0.11
