LP38502SD-ADJ

Low Dropout Linear Regulator, 1.5A, 2.7V to 5.5V, LLP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.45 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.40~0.45

PartNumber:: LP38502SD-ADJ

Brand:: National Semiconductor - NS | Pack: LLP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Gardenias's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-24

From Other Seller

Part Number:LP38502SD-ADJ
US $0.40 - 0.45
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
MSP430F5438IPZ

US $10.00 - 15.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LP38502SD-ADJ is a flexcap low dropout linear regulator for 2.7V to 5.5V inputs. National s FlexCap LDOs feature unique compensation that allows the use of any type of output capacitor with no limits on minimum or maximum ESR. The LP38502SD-ADJ of lowdropout linear regulators operates from a +2.7V to +5.5V input supply. These ultra low dropout linear regulators respond very quickly to step changes in load, which makes them suitable for low voltage microprocessor applications. Developed on a CMOS process, (utilizing a PMOS pass transistor), the LP38502SD-ADJ has low quiescent current that changes little with load current. Its applications include DSP and FPGA power supplies, SMPS regulator, conversion from 3.3V or 5V rail.

Parametrics

LP38502SD-ADJ absolute maximum ratings: (1)storage temperature range: -65 to 150℃; (2)lead temperature: 260℃; (3)ESD rating: ±2kV; (4)input pin voltage: -0.3 to 6V; (5)enable pin voltage: -0.3 to 6V; (6)output pin voltage: -0.3 to 6V; (7)IOUT: internally limited.

Features

LP38502SD-ADJ features: (1)FlexCap: Stable with ceramic, tantalum, or aluminum capacitors; (2)Stable with 10 μF input/output capacitor; (3)Adjustable output voltage from 0.6V to 5V; (4)Low ground pin current; (5)25 nA quiescent current in shutdown mode; (6)Guaranteed output current of 1.5A; (7)Available in TO-263, TO-263 THIN, and LLP-8 packages; (8)Guaranteed VADJ accuracy of ±1.5% @ 25°C (A Grade); (9)Guaranteed accuracy of ±3.5% @ 25°C (STD); (10)Over-Temperature and Over-Current protection; (11)40°C to +125°C operating TJ range; (12)Enable pin (LP38502).
