Product Summary

The BT137-600E is a triacs sensitive gate. It is intended for use in applications requiring high bidirectional transient and blocking voltage capability and high thermal cycling performance. Typical applications include motor control, industrial and domestic lighting, heating and static switching.

Parametrics

BT137-600E absolute maximum ratings: (1)repetitive peak off-state voltage: 800V; (2)RMS on-state current: 8A; (3)on-state current: 65A; (4)peak gate current: 2A; (5)peak gate voltage: 5V; (6)peak gate power: 5W; (7)storage temperature: 150℃.

Features

BT137-600E features: (1)gate trigger current: 50mA; (2)latching current: 45mA; (3)holding current: 40mA; (4)gate trigger voltage: 1.5V; (5)off-state leakage current: 0.5mA.

Diagrams

BT137-600E diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
BT137-600E
BT137-600E

Other


Data Sheet

Negotiable
BT137-600E,127
BT137-600E,127

NXP Semiconductors

Triacs RAIL TRIAC

Data Sheet

0-1: $0.46
1-25: $0.40
25-100: $0.35
100-250: $0.30
BT137-600E/L01,127
BT137-600E/L01,127

NXP Semiconductors

Triacs Thyristor TRIAC 600V 71A 3-Pin (3+Tab)

Data Sheet

0-1: $0.46
1-25: $0.40
25-100: $0.35
100-250: $0.30
