Product Summary
The HCPL06XX optocouplers consist of an AlGaAS LED, optically
coupled to a very high speed integrated photo-detector
logic gate with a strobable output (single channel devices). The
devices are housed in a compact small-outline package. This
output features an open collector, thereby permitting wired OR
outputs. The HCPL0600 and HCPL0601 output consists of
bipolar transistors on a bipolar process while the HCPL0611,
HCPL0630 and HCPL0631 output consists of bipolar transistors
on a CMOS process for reduced power consumption. The coupled
parameters are guaranteed over the temperature range of -
40°C to +85°C. A maximum input signal of 5 mA will provide a
minimum output sink current of 13 mA (fan out of 8). An internal
noise shield provides superior common mode rejection.
Features
■
Compact SO8 package
■
Very high speed-10 MBit/s
■
Superior CMR
■
Fan-out of 8 over -40°C to +85°C
■
Logic gate output
■
Strobable output (single channel devices)
■
Wired OR-open collector
■
U.L. recognized (File # E90700)
■
VDE approval pending
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HCPL0601 |
Fairchild Semiconductor |
High Speed Optocouplers 10MBit Optocoupler HS Logic Gate |
Data Sheet |
|
|
||||||||||||
|
HCPL0601_Q |
Fairchild Semiconductor |
High Speed Optocouplers 10MBit Optocoupler HS Logic Gate |
Data Sheet |
Negotiable |
|
||||||||||||
|
HCPL0601R2 |
Fairchild Semiconductor |
High Speed Optocouplers 10MBit Optocoupler HS Logic Gate |
Data Sheet |
|
|
||||||||||||
|
HCPL0601R2V |
Fairchild Semiconductor |
High Speed Optocouplers 10MBit Optocoupler HS Logic Gate |
Data Sheet |
|
|
||||||||||||
|
HCPL0601R1 |
Fairchild Semiconductor |
High Speed Optocouplers 10MBit Optocoupler HS Logic Gate |
Data Sheet |
Negotiable |
|
||||||||||||
|
HCPL0601R1V |
Fairchild Semiconductor |
High Speed Optocouplers 10MBit Optocoupler HS Logic Gate |
Data Sheet |
Negotiable |
|
||||||||||||
|
HCPL0601V |
Fairchild Semiconductor |
High Speed Optocouplers 10MBit Optocoupler HS Logic Gate |
Data Sheet |
|
|
||||||||||||
