M29W128GL70N6E

flash memory, 3V, 30A, TSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.29~2.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.29~2.30

PartNumber:: M29W128GL70N6E

Brand:: Numonyx B.V - Numonyx | Pack: TSOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Gardenias's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-04

From Other Seller

Part Number:M29W128GL70N6E
US $2.29 - 2.30
MOC3063

US $0.32 - 1.50 / Piece
(0) Remove
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The M29W128GL70N6E is a 3V supply flash memory. The M29W128GL70N6E is divided into 64-Kword/128-Kbyte uniform blocks that can be erased independently so it is possible to preserve valid data while old data is erased. Program and Erase commands are written to the command interface of the memory. An on-chip Program/Erase controller simplifies the process of programming or erasing the memory by taking care of all of the special operations that are required to update the memory contents.The end of a program or erase operation can be detected and any error conditions identified.

Parametrics

M29W128GL70N6E absolute maximum ratings: (1)temperature under bias: -50 to 125℃; (2)storage temperature: -65 to 150℃; (3)input or output voltage: -0.6 to VCC+0.6V; (4)identification voltage: -0.6 to 13.5V; (5)program voltage: -0.6 to 13.5.

Features

M29W128GL70N6E features: (1)Supply voltage, VCC = 2.7 to 3.6 V for Program, Erase and Read; (2)Asynchronous Random/Page Read: Page size: 8 words or 16 bytes, Page access: 25, 30 ns, Random access: 60 (only available upon customer request) or 70, 80 ns; (3)Fast Program commands, 32 words (64-byte write buffer); (4)Enhanced Buffered Program commands, 256 words; (5)Programming time.
