Product Summary
The ADG212AKR is a quad spst switch. It is a monolithic CMOS devices comprising four independently selectable switches. They are designed on an enhanced LC2MOS process, which gives an increased signal handling capability of ±15 V. These switches also feature high switching speeds and low RON. The ADG212AKR consists of four SPST switches. They differ only in that the digital control logic is inverted.
Parametrics
ADG212AKR absolute maximum ratings: (1)VDD to VSS: 44V; (2)VDD to GND: 25V; (3)VSS to GND: -25V; (4)VL to GND: -0.3V; (5)Analog inputs, continuous current: 30mA; (6)power dissipation: 470mW; (7)lead temperature: 300℃.
Features
ADG212AKR features: (1)44 V supply maximum rating; (2)±15 V analog signal range; (3)Low RON: 115 Ω maximum; (4)Low leakage: 0.5 nA typical; (5)Break-before-make switching; (6)Single supply operation possible; (7)Extended plastic temperature range: -40°C to +85°C; (8)TTL/CMOS compatible.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADG212AKR |
|
IC SWITCH QUAD SPST 16SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
ADG212AKR-REEL |
|
IC SWITCH QUAD SPST 16SOIC |
Data Sheet |
Negotiable |
|
||||||||||||||||||
|
ADG212AKRZ |
|
IC SWITCH QUAD SPST 16SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
ADG212AKRZ-REEL |
|
IC SWITCH QUAD SPST 16SOIC |
Data Sheet |
|
|
||||||||||||||||||
