Product Summary
CELL(lithium-ion rechargeable cell)
Parametrics
、Nominal Capacity | 2200mAh (0.2C, 2.75V discharge) |
2、Minimum Capacity | 2550mAh(0.2C, 2.75V discharge) |
3、Charging Voltage | 4.2 ±0.05 V |
4、Nominal Voltage | 3.7V |
5、Charging Method |
CC-CV (constant voltage with limited current) |
6、Charging Current |
Standard charge: 1300mA Rapid charge : 2600mA |
7、Charging Time |
Standard charge : 3hours Rapid charge : 2.5hours |
8、Max. Charge Current | 2600mA(ambient temperature 25℃) |
9、Max. Discharge Current | 5200mA(ambient temperature 25℃) |
10、Discharge Cut-off Voltage | 2.75V |
11、Cell Weight | 47.0g max |
12、Cell Dimension |
Height : 65.00mm max Diameter : 18.40mm max |
13、Operating Temperature |
Charge : 0 to 45℃ Discharge: -20 to 60℃ |
14、 Storage Temperature |
1 y e ar : -20~25℃(1*) 3 months : -20~45℃(1*) 1 month : -20~60℃(1*) |
Features
Nominal Capacity 2600mAh (0.2C, 2.75V discharge)
Minimum Capacity 2550mAh (0.2C, 2.75V discharge)
Charging Voltage 4.2 ±0.05 V
Nominal Voltage 3.7V
Charging Method CC-CV (constant voltage with limited current)
Charging Current Standard charge : 1300mA
Rapid charge : 2600mA
Charging Time Standard charge : 3hours
Rapid charge : 2.5hours
Max. Charge Current 2600mA(ambient temperature 25℃)
Max. Discharge Current 5200mA(ambient temperature 25℃)
Discharge Cut-off Voltage 2.75V
Cell Weight 47.0g max
Cell Dimension Height : 65.00mm max
Diameter : 18.40mm max
Operating Temperature
Charge : 0 to 45℃ Discharge : -10 to 60℃
Storage Temperature
1 year : -20~25℃(1*) 3 months : -20~45℃(1*) 1 month : -20~60℃(
